Features
- Designed for fully tiled in installations
- Constructed from High Density Polyethylene
- Polystyrene insulation jacket to prevent condensation & allow for quiet re-filling
- Top or front flush plate mounting
- With an internal isolation valve
- WRAS approved & tested to the highest industry standards
- Featuring a pneumatic dual flush valve 3/6L cistern
- All parts are easy to maintain & serviceable through flush plate aperture
- 0.2 - 10.0 bar working pressure range
- 90° flush pipe for neat installation
- Flush pipe securing bracket
- Side entry inlet valve (1/2” BSP)
- Rigorously tested before leaving factory
- Width: 600mm
- Depth: 138-194mm
- Height: max 745mm
- 1-year manufacturer's guarantee
Technical Specification
| Manufacturer | Tavistock |
| Colour | White |
| SKU | TR9009 |
| Material | High-Density Polyethylene |
| Width | 600mm |
| Depth | 138-194mm |
| Height | max 745mm |
| Inlet | Side |
| Flush | Dual 3/6 L |
| Connection | 90° flush pipe pre-fitted |
| Operation | Pneumatic |
| Working Pressure | 0.2 - 10.0 bar |
| Guarantee | 1-Year |
